The proliferation of enormous diffusion models for image generation has led to a big improve in mannequin measurement and inference workloads. On-device ML inference in cell environments requires meticulous efficiency optimization and consideration of trade-offs on account of useful resource constraints. Working inference of enormous diffusion fashions (LDMs) on-device, pushed by the necessity for price effectivity and consumer privateness, presents even higher challenges as a result of substantial reminiscence necessities and computational calls for of those fashions.

We deal with this problem in our work titled “Speed Is All You Need: On-Device Acceleration of Large Diffusion Models via GPU-Aware Optimizations” (to be offered on the CVPR 2023 workshop for Efficient Deep Learning for Computer Vision) specializing in the optimized execution of a foundational LDM mannequin on a cell GPU. On this weblog submit, we summarize the core strategies we employed to efficiently execute giant diffusion fashions like Stable Diffusion at full decision (512×512 pixels) and 20 iterations on fashionable smartphones with high-performing inference pace of the unique mannequin with out distillation of beneath 12 seconds. As mentioned in our previous blog post, GPU-accelerated ML inference is usually restricted by reminiscence efficiency, and execution of LDMs isn’t any exception. Due to this fact, the central theme of our optimization is environment friendly reminiscence enter/output (I/O) even when it means selecting memory-efficient algorithms over those who prioritize arithmetic logic unit effectivity. In the end, our main goal is to cut back the general latency of the ML inference.

A pattern output of an LDM on Cell GPU with the immediate textual content: “a photograph life like and excessive decision picture of a cute pet with surrounding flowers”.

Enhanced consideration module for reminiscence effectivity

An ML inference engine sometimes gives quite a lot of optimized ML operations. Regardless of this, attaining optimum efficiency can nonetheless be difficult as there’s a specific amount of overhead for executing particular person neural web operators on a GPU. To mitigate this overhead, ML inference engines incorporate in depth operator fusion guidelines that consolidate a number of operators right into a single operator, thereby decreasing the variety of iterations throughout tensor components whereas maximizing compute per iteration. As an illustration, TensorFlow Lite makes use of operator fusion to mix computationally costly operations, like convolutions, with subsequent activation features, like rectified linear units, into one.

A transparent alternative for optimization is the closely used consideration block adopted within the denoiser model within the LDM. The eye blocks enable the mannequin to give attention to particular elements of the enter by assigning increased weights to vital areas. There are a number of methods one can optimize the eye modules, and we selectively make use of one of many two optimizations defined under relying on which optimization performs higher.

The primary optimization, which we name partially fused softmax, removes the necessity for in depth reminiscence writes and reads between the softmax and the matrix multiplication within the consideration module. Let the eye block be only a easy matrix multiplication of the shape Y = softmax(X) * W the place X and W are 2D matrices of form a×b and b×c, respectively (proven under within the high half).

For numerical stability, T = softmax(X) is usually calculated in three passes:

  1. Decide the utmost worth within the listing, i.e., for every row in matrix X
  2. Sum up the variations of the exponential of every listing merchandise and the utmost worth (from move 1)
  3. Divide the exponential of the gadgets minus the utmost worth by the sum from move 2

Finishing up these passes naïvely would lead to an enormous reminiscence write for the momentary intermediate tensor T holding the output of your entire softmax operate. We bypass this huge reminiscence write if we solely retailer the outcomes of passes 1 and a pair of, labeled m and s, respectively, that are small vectors, with a components every, in comparison with T which has a·b components. With this system, we’re in a position to cut back tens and even tons of of megabytes of reminiscence consumption by a number of orders of magnitude (proven under within the backside half).

Consideration modules. High: A naïve consideration block, composed of a SOFTMAX (with all three passes) and a MATMUL, requires a big reminiscence write for the large intermediate tensor T. Backside: Our memory-efficient consideration block with partially fused softmax in MATMUL solely must retailer two small intermediate tensors for m and s.

The opposite optimization includes using FlashAttention, which is an I/O-aware, actual consideration algorithm. This algorithm reduces the variety of GPU high-bandwidth reminiscence accesses, making it match for our reminiscence bandwidth–restricted use case. Nonetheless, we discovered this system to solely work for SRAM with sure sizes and to require a lot of registers. Due to this fact, we solely leverage this system for consideration matrices with a sure measurement on a choose set of GPUs.

Winograd quick convolution for 3×3 convolution layers

The spine of widespread LDMs closely depends on 3×3 convolution layers (convolutions with filter measurement 3×3), comprising over 90% of the layers within the decoder. Regardless of elevated reminiscence consumption and numerical errors, we discovered that Winograd fast convolution to be efficient at dashing up the convolutions. Distinct from the filter measurement 3×3 utilized in convolutions, tile measurement refers back to the measurement of a sub area of the enter tensor that’s processed at a time. Growing the tile measurement enhances the effectivity of the convolution when it comes to arithmetic logic unit (ALU) utilization. Nonetheless, this enchancment comes on the expense of elevated reminiscence consumption. Our exams point out {that a} tile measurement of 4×4 achieves the optimum trade-off between computational effectivity and reminiscence utilization.

    Reminiscence utilization
    Tile measurement         FLOPS financial savings         Intermediate tensors         Weights
2×2 2.25× 4.00× 1.77×
4×4 4.00× 2.25× 4.00×
6×6 5.06× 1.80× 7.12×
8×8 5.76× 1.56× 11.1×

Impression of Winograd with various tile sizes for 3×3 convolutions.

Specialised operator fusion for reminiscence effectivity

We found that performantly inferring LDMs on a cell GPU requires considerably bigger fusion home windows for generally employed layers and models in LDMs than present off-the-shelf on-device GPU-accelerated ML inference engines present. Consequently, we developed specialised implementations that might execute a bigger vary of neural operators than typical fusion guidelines would allow. Particularly, we centered on two specializations: the Gaussian Error Linear Unit (GELU) and the group normalization layer.

An approximation of GELU with the hyperbolic tangent operate requires writing to and studying from seven auxiliary intermediate tensors (proven under as gentle orange rounded rectangles within the determine under), studying from the enter tensor x 3 times, and writing to the output tensor y as soon as throughout eight GPU applications implementing the labeled operation every (gentle blue rectangles). A customized GELU implementation that performs the eight operations in a single shader (proven under within the backside) can bypass all of the reminiscence I/O for the intermediate tensors.

GELU implementations. High: A naïve implementation with built-in operations would require 8 reminiscence writes and 10 reads. Backside: Our customized GELU solely requires 1 reminiscence learn (for x) and 1 write (for y).


After making use of all of those optimizations, we performed exams of Steady Diffusion 1.5 (picture decision 512×512, 20 iterations) on high-end cell gadgets. Working Steady Diffusion with our GPU-accelerated ML inference mannequin makes use of 2,093MB for the weights and 84MB for the intermediate tensors. With newest high-end smartphones, Steady Diffusion could be run in beneath 12 seconds.

Steady Diffusion runs on fashionable smartphones in beneath 12 seconds. Be aware that working the decoder after every iteration for displaying the intermediate output on this animated GIF ends in a ~2× slowdown.


Acting on-device ML inference of enormous fashions has confirmed to be a considerable problem, encompassing limitations in mannequin file measurement, in depth runtime reminiscence necessities, and protracted inference latency. By recognizing reminiscence bandwidth utilization as the first bottleneck, we directed our efforts in the direction of optimizing reminiscence bandwidth utilization and putting a fragile stability between ALU effectivity and reminiscence effectivity. Because of this, we achieved state-of-the-art inference latency for giant diffusion fashions. You’ll be able to be taught extra about this work in the paper.


We might prefer to thank Yu-Hui Chen, Jiuqiang Tang, Frank Barchard, Yang Zhao, Joe Zou, Khanh LeViet, Chuo-Ling Chang, Andrei Kulik, Lu Wang, and Matthias Grundmann.
